| Type | M Load Capacity | Total Length (mm) | Idler Hub/ Bolt Hub | Tube Size | Axle Shape | Spindle Size | Hub Fae/Spring Center |
| USA Models | 2000 LB | Customized | 4×4″, 5×4.5″ | 1×3/4″ | Round | 1″, 1-1/16″ | 61″/46″ |
| 3500 LB | Customized | 5×4.5” 5×4.75” 5x 5” 5×5.5” 6×5.5” | 2-3/8” | Round | 1-3/8x 1-1/16” | 73/58″ 85/70” 89/74”95/80” | |
| 5200 LB | Customized | 6×5.5″ | 3″ | Round | 1-3/4″ x 1-1/4″ | 73/58”85/70” 89/74”95/80” | |
| 7000 LB | Customized | 8×6.5″ | 3″ | Round | 1-3/4″ x 1-1/4″ | 73/58” 85/70” 89/74” 95/80” | |
| 8000 LB | Customized | 8 x 6.5″ | 3-1/2″ | Round | 1-3/4″ x 1-1/4″ | 73/58” 85/70” 89/74”95/80” |
| Type | Load Capacity | Track Length (mm) | Bolt Pattern | Alxe Size | Axle Shape | Bearing |
| Australia Type | 750 KG | Customized | 4x100mm, 5x100mm | 39 mm | Round | LM Parallel |
| 1000 – 1200 KG | Customized | 4×4”, 5×4.25”, 5×4.5” | 45 mm | Round | Slimline | |
| 1450 – 1600 KG | Customized | 4×139.7mm, 5×4.25, 5×4.5”, 5×4.5”, 5x150mm, 6×139.7mm | 50 mm | Round | LM Slimline | |
| 2500 KG | Customized | 5×5.5”, 5x150mm, 6×139.7mm | 65 mm | Round | 2.0 Tonne | |
| 3500 KG | Customized | 5x 150mm, 6 x 139.7mm, 6 x 205mm | 75 mm | Round | 3.0 Tonne |
FAQ
1. Who are we?
We are the manufacturer and exporter of trailer parts and truck parts.
2. What spare parts can you buy from us?
Axle, Brake Drum, Brake Hub, Leaf Spring, Suspension and Suspension Kits, Trailer Jack, Landing Gear, Air Tank, Air Brake Chamber…
3. What’s the MOQ?
Depends on the different products and different order quantity.
The larger the quantity is, the competitive price will be.
4. How can we guarantee the quality?
The samples can be provided before mass production.
One by one inspection after production and before shipment.
5. What’s the packing?
Standard export carton, pallet. The packing also can be customized as requested.
6. Can the logo or label be customized here?
Yes, the logo or label can be customized as requested.
7. What’s the delivery time?
The standard production time is 20 – 30 days.
The exact delivery time will be confirmed as per the order quantity.
8. What’s the payment term?
T/T, Paypal, Western Union, L/C.
30% deposit before production, 70% balance before delivery.
It can be negotiated when confirming the order.
9. What’s the shipping methods?
BY Sea, by air, by express. We will provide suggestion as per the goods.
10. What is your sample policy?
The samples can be provided, but the customers need to bear the sample cost and the courier cost.
11. Can you produce according to the samples or drawings?
Yes, we can provide the custom services.
12. How do you make our business long-term and good relationship?
We keep good quality and competitive price to ensure our customers benefit.
